Ana sayfa /Ürünler/UV Vernikleme Makinesi/High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm

High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm

1 takım
MOQ
To Be Negotiated
fiyat
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm
Özellikleri Fotoğraf Galerisi Ürün Açıklaması Fiyat talebi
Özellikleri
Teknik Özellikler
Ürün adı: Yüksek Hızlı 9500 Yaprak/Saat UV Noktası ve Toplam Kaplama Makinesi
Maks.Lifesi Boyutu: Maks.Lifesi Boyutu
En fazla kaplama boyutu: 720x1050mm
Sayfa kalınlığı: 80-500gsm
Maksimum kaplama kalınlığı: 0.025mm
Kaplama Ortamı: Su Bazlı Vernik veya UV Vernik
Vurgulamak:

Max Coating Size 720x1050mm UV Varnishing Machine

,

Sheet Thickness 80-500gsm UV Coating Machine

,

Max Coating Thickness 0.025mm Spot and Overall Coating Machine
Temel bilgiler
Menşe yeri: Çin
Marka adı: EcooGraphix
Sertifika: CE
Model numarası: Ecoo SD-1060W
Ödeme & teslimat koşulları
Ambalaj bilgileri: Standart İhracat Paketi
Teslim süresi: 45 gün
Ödeme koşulları: L/C,T/T
Yetenek temini: 200 set/yıl
Ürün Açıklaması
High Speed 9500 Sheets/hour UV Spot and Overall Coating Machine
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 0
Model: Ecoo SD-1060W
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 1
Product Parameters

The High Speed UV Spot and Overall Coating machine SD1060W features:

  • Upper-sway gripper-pass-sheet method enabling maximum speed of 9500 sheets/hour
  • UV curing system with Teflon conveying belt for higher speed and precise orientation
  • UV curing higher efficiency with lower power consumption
  • Suitable for both thick and thin papers (80-500gsm)
  • Capable of both full and partial UV varnish coating or water based varnish coating
Application Sample
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 2
Specification
Model Ecoo SD-1060W
Max.sheet size 730x1060mm
MIN.sheet size 310X406mm
Max.coating size 720x1050mm
Sheet thickness 80-500gsm
Max Coating Thickness 0.025mm
Coating Media Water Base Varnish or UV Varnish
Coating registration accuracy ±0.2mm
Production speed 9000 sheets/hour
Weight 8 Ton
Dimension 10460x2725x1930mm
Power Max 44KW
Floor Plan
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 3
Coating Rollers
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 4
Coating with Anilox Roller
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 5
Coating with Rubber roller
FAQ
Q: What about the Installation and after-sales technician support?

A: Our engineer can assist with installation and provide necessary training. The buyer is responsible for round air plane tickets, service charge, and local accommodation costs. We provide 24/7 support for any questions or issues.

With numerous CTP installations worldwide, including direct purchases from EcooGraphix China, our technical service team supports these installations remotely with regular onsite visits. Our satisfied customers benefit from robust quality, seamless remote service, thorough training, and maintenance.

FACTORY
High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 6 High Speed 9500 Sheets/hour UV Varnishing Machine with Max Coating Size 720x1050mm and Sheet Thickness 80-500gsm 7
